首页 / 全部产品 / SAE法兰盲板 有槽
产品图片

SAE法兰盲板 有槽

sae-closed-flange

型号: 12PMT3-O

¥32.00 库存:

SAE法兰盲板 有槽 产品明细

当前选择：12PMT3-O
压力等级：3000PSI
电话咨询

SAE法兰盲板 有槽产品详情

暂无详细描述

SAE法兰盲板 有槽规格尺寸对照表

SAE法兰盲板 有槽产品图纸
SAE法兰盲板 有槽技术规格尺寸图

12PMT3-O 型号说明：

暂无型号说明

Ordering code: 订货说明

Carbon steel 碳钢 Stainless steel 不锈钢
Flange only 只有法兰
SAE法兰盲板 有槽 - 3000PSI
Normal
Size
inch		 编号
Type		 尺寸 Measurement 配用
附件
Accessories		 单重
kg		 最大工作
压力
Kg/cm²
C D E F H K 螺栓
Bolt		 O形圈
Oring
3/4" 12PMT3-O 47.63 65 22.23 50.00 16.00 11.00 M10x35 25.00ⅹ3.53 0.30 345
1" 16PMT3-O 52.37 70 26.19 55.00 19.00 11.00 M10x35 32.92ⅹ3.53 0.37 345
1-1/4" 20PMT3-O 58.72 79 30.18 68.00 18.00 11.50 M10x40 37.70ⅹ3.53 0.54 276
1-1/2" 24PMT3-O 69.85 93 35.71 78.00 20.00 13.50 M12x45 47.22ⅹ3.53 0.90 207
2" 32PMT3-O 77.77 102 42.88 90.00 20.00 13.50 M12x45 56.75ⅹ3.53 1.00 207
2-1/2" 40PMT3-O 88.90 114 50.80 105.00 20.00 13.50 M12x45 69.45ⅹ3.53 1.35 172
3" 48PMT3-O 106.38 134 61.93 124.00 24.00 17.50 M16x50 85.32ⅹ3.53 2.50 138
3-1/2" 56PMT3-O 120.65 152 69.85 136.00 22.00 17.50 M16x50 98.02ⅹ3.53 2.90 35
4" 64PMT3-O 130.18 162 77.77 146.00 25.00 17.50 M16x50 110.72ⅹ3.53 3.90 35
5" 80PMT3-O 152.40 190 92.08 170.00 28.00 17.50 M16x55 136.12ⅹ3.53 5.90 35
1/2" 8PMT3-O 38.10 54 17.48 46.00 16.00 9.00 M8x30 18.66ⅹ3.53 0.20 345
SAE法兰盲板 有槽 - 6000PSI
Normal
Size
inch		 编号
Type		 尺寸 Measurement 配用
附件
Accessories		 单重
kg		 最大工作
压力
Kg/cm²
C D E F H K M O形圈
3/4" 12PMT6-O 50.80 71 23.80 55.00 19.00 11.00 M10x35 25.00ⅹ3.53 0.45 400
1" 16PMT6-O 57.15 81 27.78 65.00 24.00 13.50 M12x45 32.92ⅹ3.53 0.77 400
1-1/4" 20PMT6-O 66.68 95 31.76 78.00 27.00 15.00 M14x45 37.70ⅹ3.53 1.15 400
1-1/2" 24PMT6-O 79.38 112 36.52 94.00 30.00 17.00 M16x45 47.22ⅹ3.53 1.82 400
2" 32PMT6-O 96.82 134 44.45 114.00 28.00 21.00 M20x65 56.75ⅹ3.53 2.43 400
2-1/2" 40PMT6-O 123.80 180 58.80 152.00 45.00 25.00 M24x80 75.57ⅹ5.33 7.25 400
3" 48PMT6-O 152.40 208 71.60 178.00 55.00 32.00 M30x100 88.27ⅹ5.33 11.78 400
1/2" 8PMT6-O 40.49 54 18.24 46.00 16.00 9.00 M8x30 18.66ⅹ3.53 0.24 400

SAE法兰型号对照表

19 条结果
规格尺寸 压力等级 型号 伊顿（EATON） ANCHOR FLUID POWER Flanges 汉莎（HANSA-FLEX） 派克（Parker） 西德福（STAUFF）
12PMT3-O 3000PSI 12PMT3-O
16PMT3-O 3000PSI 16PMT3-O
20PMT3-O 3000PSI 20PMT3-O
24PMT3-O 3000PSI 24PMT3-O
32PMT3-O 3000PSI 32PMT3-O
40PMT3-O 3000PSI 40PMT3-O
48PMT3-O 3000PSI 48PMT3-O
56PMT3-O 3000PSI 56PMT3-O
64PMT3-O 3000PSI 64PMT3-O
80PMT3-O 3000PSI 80PMT3-O
8PMT3-O 3000PSI 8PMT3-O
12PMT6-O 6000PSI 12PMT6-O
16PMT6-O 6000PSI 16PMT6-O
20PMT6-O 6000PSI 20PMT6-O
24PMT6-O 6000PSI 24PMT6-O
32PMT6-O 6000PSI 32PMT6-O
40PMT6-O 6000PSI 40PMT6-O
48PMT6-O 6000PSI 48PMT6-O
8PMT6-O 6000PSI 8PMT6-O
